Materiał
FR-4, CEM-1, CEM-3, Hight TG, FR4 Halogen Free, FR-1, FR-2, aluminium
Wykończenie powierzchni / leczenie
HALS / HALS bezołowiowe, cyna chemiczna, chemiczne złoto, Immersion złota Inmersion srebrny / złoty, OSP, złocenie
Orzecznictwo
UL Zatwierdzenie
ROHS
ISO9001: 2000
certyfikat CE
SGS ołowiu certyfikacja
Co możemy dla Ciebie zrobić?
Świadczymy następujące usługi dla wszystkich naszych klientów:
1. Usługa produkcji PCB. Dostępne na FR-4, TG150-180, aluminium, FPC
2. PCB kopiowanie usługi
3. PCB usługi montażu. Dostępne na SMT, BGA, DIP.
4. A Box budowy montażu. Dostępne na końcowe testy funkcjonalne i pakiet końcowego
Usługa zakupów 5. Części elektroniczne
Poniższe informacje są wymagane dla tej usługi:
* Pliki Gerber z gołej PCB
* Zestawienie materiałów obejmują: Numer części producenta, typ strony, rodzaj opakowania, lokalizacje elementów wymienionych przez oznaczników referencyjnych i ilości
* Dane wymiarowe dla niestandardowych elementów
* Rysunek montażu, włącznie z wszelkimi zmianami ogłoszeń
* Procedury testowe końcowy (jeśli jest dostępny)
Szczegóły Produktu:
Zapłata:
|
| Base Material: | FR4 | Board Thickness: | 1.6mm |
|---|---|---|---|
| Copper Thickness: | 1OZ | layer: | 2-8 layer PCB |
| Solder Type: | Water Solder Paste | Surface Finishing: | HASL |
| High Light: | pcb assembly services,surface mount pcb assembly |
||
Welcome to Rigao Electronics .CO.,Ltd.
Single-side,double-sided and multilayer PCB and PCB Assembly manufacturer/OEM
- Contract Manufacturing
- Mixed-technology (High speed SMT & Through hole assembly)
- PCB Design & Assembly and copy service
- Prototyping
- Components purchasing
- Metal box,Coil,Cable and Wire Assemblies
- Plastics and Molds
| PCB Assembly Specifications | |
| Quantity | Prototype and small to middle volume are our specialty |
| Type of Assembly | SMT and Thru-hole |
| Type of Service | Turn-Key, Partial Turn-Key or Consignment |
| Solder Type | Water Soluble Solder Paste, Leaded and Lead-Free |
| File Formats | Bill of Materials |
| Gerber Files | |
| Pick-N-Place File (XYRS) | |
| Bare Board Size | Smallest: 0.25 x 0.25 Inches |
| Largest: 20 x 20 Inches | |
| Components | Passives Down to 0201 Size |
| BGA and VFBGA | |
| Leadless Chip Carriers/ CSP | |
| Double-Sided SMT Assembly | |
| BGA Repair and Reball | |
| Part Removal and Replacement | |
| Component Packaging | Cut Tape,Tube,Reels,Loose Parts |
| Turn Time | Same Day Service to 15 day service |
| Testing | X-RAY Inspection & AOI Test |
PCB Assembly Technical Capability
We deliver high quality surface-mount technology (SMT) products through the use of modern, well maintained SMT lines that are operated by trained professionals. Our SMT lines are capable of handling both low and high volume through-put, can perform single and double sided component placement, mixture of SMT automatic and manual component assemblies, SMT and through-hole assemblies.
Capability 1.SMT with 4 million placements per day
2.Manual insertion with output 500,000pcs components per day
3.Chip mounting speed is 0.3S/unit,high-point speed is 0.16S/unit
Mount Precision: 1.Chips size:Min.0201
2.Mounting precision:0.1mm
3.Multi-functional machine can match 0.3 pitch packages such as BGA,CSP
Application
Products are applied to a wide range of High-tech industries such as: LED lighting,telecommunication, computer application, lighting, game machine, industrial control, power,automobile and high-end consumer electronics, ect.
By unremitting work and effort to the marketing, products exports to American,Canada, Europe counties,Africa and other Asia-pacific countries.
Quality Certificates
Lead free,ISO,UL,CE
View of Rigao Factory
Our Principle is simple, “Act by heart, Make the best.”
Our strengthis distinct, “Years of experiences in PCB and PCBA field”
Our Goal is achievable, “ To be the most reliable supplier of PCB and PCBA.”
Our orientation is clear, “Focus on prototypes and low to medium volume business ”
